Complete Simulation of
IEC 104 Server as per Protocol
Standard including File transfer
(Both Monitoring and control direction).
​Support all type of
ASDU Typeid according to protocol specification 1) Monitoring (Process information in monitor
direction), M_SP. M_DP, M_ST,... 2) control (Process information in control
direction), C_SC, C_DC, ... 3) System information in monitor direction,
M_EI 4) System
information in control direction C_IC, C_CI 5) Parameter in control direction, P_ME 6) File transfer ( Both Monitor And Control
Direction) F_FR, F_SR, F_SC
FreyrSCADA IEC 60870-5-104 Server
Simulator was originally developed to test the IEC 60870-5-104 stack. We
developed the stack to run multiple hardware platform (windows, Linux,
RTLinux, QNX..). So we had to test multiple platform. At that time,
our engineers, developed the test simulation application. We
tested this simulator with multiple test software available in the
market.
Our
support team has young, dynamic and professional team of engineers.
Our Engineers will provide the quick and accurate solution as per
customer requirement. We
can add up to 50 server node in the simulator. Every server node will
work independently. Simulator
window shows the status and connection ip address, port number,
redundancy enabled or not,If Redundancy enabled it shows, the
redundant source ip address, port . The
user can update the monitoring Point information.The following
parameters can change Value and quality bits.
Features
Complete Simulation of IEC 104 Protocol
Multiple
Server Simulation
In
a Single Server(link) simulate Multiple Stations (Common Address)
Redundancy
Enabled
Mapping
of Control Point to monitor Information point, consider C_SC point
can map to M_SP point
Communication
with redundant control systems and interruption-free switchover
between redundant systems
Supports
"select-before-operate" or "direct-execute" command execution
modes
New updated Version of IEC 60870-5-104
Simulator & SDK (Software Development Kit) is available now. In the Development Bundle, We included IEC 104
Server & Client Simulator, Windows and Linux SDK, C# projects, Doxygen
documentation and Raspberry Pi, BeagleBone Demo library.
In
this License model, We deliver Simulator Installer for Windows
Operating System.
The Customer can use the software company wide. Customer can install
the software in many systems.
There is no restriction like Hardware key (Dongle) and software key.
